Miler Millermatic 142 Mig Welder
120v 50/60hz 1ph - 907838
USD $1,189.00
Condition : New
Free Shipping
Notify me when the price drops
We will email you if we find a lower price on this product!
- Miller Products
- Welding Tips
- Tig Torches
- Welding Guns
- Welders
- Accessories
- Miscellaneous
- Safety Apparel
- Cutting Tips
- Gas Apparatus
- Abrasives
- Others
- View Store
- View Feedback
- Add to Favorites
- Send Message
The New Millermatic 142 Is the perfect choice for the DIY to the light industrial levels. Capable of MIG and flux cored 120 V welds from 24 gauge – 3/16 in. mild steel.
WHAT'S INCLUDED
Millermatic 142
10-ft. (3 m) MDX™-100 MIG Welding Gun
10-ft. (3 m) work cable with clamp
6.5-ft. (2 m) power cord with plug
Argon and AR/CO2 mix flow gauge regulator with gas hose
Hobart® spool of .030-in. (0.8 mm) solid wire
Two contact tips for .030-in. (0.8 mm) wire
Quick Select drive rolls for .024-in (0.6 mm) or .030/.035-in. (0.8/0.9 mm) solid wire, and .030/.035-in. (0.8/0.9 mm) flux-cored wire
Material thickness gauge (#229 895)
Hook-and-loop cord wraps
Auto-Set™
A breakthrough control that automatically sets your welder to the proper parameters. Auto-Set offers all-in-one MIG minus the hassle of finding parameters. Simply set the wire diameter, set the material thickness, and start welding!
Segmented Display
Easy to read display gives you the flexibility to set the machine precisely and accurately in Manual and Auto-Set modes.
120V Input Power
Uses 120V household input power so there is no special power requirements. Flexible to use in any location!
Smooth-Start™
This technology provides a smooth, spatter-free start. The best starting machine in the 120V MIG category! No more pop-gun starts or spatter to clean up.
Thermal Overload & 'Tip Saver' Short Circuit Protection
Shuts down the unit and activates the over-temperature light if the airflow is blocked or duty cycle is exceeded. Tip Saver shuts down output when the tip is shorted to the work extending tip life and protecting internal components from damage.
Auto Spool Gun Detect™
Automatically detects when a MIG gun or spool gun is connected eliminating the need for a switch.
Quick Select™ Drive Roll
Makes setup quicker by offering three grooves - two for different size solid wire and a third for flux-cored wire.
Generator Compatible
The Millermatic 141 will be able to operate and provide full output when powered by generators with 4500 Watt (4.5K) output or higher, such as a Miller Blue Star 185 (6200 watts) or Fusion 160 (6200 watts) generator. Limited output will occur when used with smaller generators.
PROCESSES
Flux Cored (FCAW)
MIG (GMAW)
GENERAL SPECIFICATIONS
Title
Millermatic® 142 MIG Welder
Industries Interests
Racing
Farm and Ranch
Manufacturing
Welding Education and Training
Amperage
30 A - 140 A
Material Thickness
Aluminum 18 ga. (1.2 mm) - 14 ga. (1.9 mm)
Mild Steel 24 ga. (0.8 mm) - 3/16 in. (4.8 mm)
Weldable Metals
Aluminum
Stainless Steel
Steel
Input Voltage
110/115/120 V
Input Phase
1-Phase
Input Hz
60 Hz
Current Type
DC
Rated Output
100 A at 19 V, 60% duty cycle 80 A at 18 V, 100% duty cycle
Max Open Circuit Voltage
30 VDC
Wire Feed Speed
1.5 m/min - 15.2 m/min
60 IPM - 600 IPM
Wire Diameter
Stainless 0.024 in. - 0.03 in.
Stainless 0.6 mm. - 0.8 mm.
Solid Steel 0.6 mm. - 0.8 mm.
Solid Steel 0.024 in. - 0.03 in.
Flux Cored 0.03 in. - 0.035 in.
Flux Cored 0.8 mm. - 0.9 mm.
Spool Size
8 in.
Portability
Handle(s)
Running Gear / Cart (Optional)
Weld Output
CV
Applications
Car Restoration
Garage/Shop
Metal Art
Welding Projects
